| Model |
|
HR052BA2H |
|
HR052BA |
| HR052BC |
|
HR060BE |
|
HR060BG |
| Power Consumption(W) |
|
50W |
|
52W |
|
52W |
|
60W |
|
60W |
|
|
|
|
|
|
|
|
|
|
|
| Dimension(mm) |
|
612×612×56 |
|
604×604×24 |
|
604×604×56 |
|
604×604×24 |
|
604×604×56 |
|
|
|
|
|
|
|
|
|
|
|
| Base |
|
Lighting apparatus all-in-one |
|
Lighting apparatus all-in-one |
|
Lighting apparatus all-in-one |
|
Lighting apparatus all-in-one |
|
Lighting apparatus all-in-one |
|
|
|
|
|
|
|
|
|
|
|
| Input Voltage(V) |
|
AC 220 |
|
AC 220 |
|
AC 220 |
|
AC 220 |
|
AC 220 |
|
|
|
|
|
|
|
|
|
|
|
| Power Factor |
|
more than 0.95 |
|
more than 0.95 |
|
more than 0.95 |
|
more than 0.95 |
|
more than 0.95 |
|
|
|
|
|
|
|
|
|
|
|
| Luminous Flux(lumen) |
|
4,385 |
|
5,180 |
|
5,100 |
|
6,460 |
|
5,940 |
|
|
|
|
|
|
|
|
|
|
|
| Luminaire Efficiency(lm/W) |
|
87 |
|
99 |
|
98 |
|
107 |
|
99 |
|
|
|
|
|
|
|
|
|
|
|
| Color Temperature(K) |
|
5,700 |
|
5,700 |
|
5,700 |
|
5,700 |
|
5,700 |
|
|
|
|
|
|
|
|
|
|
|
| CRI(Ra) |
|
80 |
|
80 |
|
82 |
|
80 |
|
82 |
|
|
|
|
|
|
|
|
|
|
|
| Lifespan(H) |
|
50,000 |
|
50,000 |
|
50,000 |
|
50,000 |
|
50,000 |
|
|
|
|
|
|
|
|
|
|
|
| Beam Angle(˚) |
|
120 |
|
100 |
|
120 |
|
100 |
|
120 |
|
|
|
|
|
|
|
|
|
|
|
| Weight(g) |
|
5,600 |
|
3,700 |
|
3,900 |
|
3,700 |
|
3,900 |
|
|
|
|
|
|
|
|
|
|
|
| Lighting pattern |
|
Diffused Lighting |
|
Arch |
|
Diffused Lighting |
|
Arch |
|
Diffused Lighting |
|
| *Specification could be changed without notice. |
| Model |
|
HR050BB2H |
|
HR052BB |
|
HR052BD |
|
HR060BF |
|
HR060BH |
| Power Consumption(W) |
|
52W |
|
52W |
|
52W |
|
60W |
|
60W |
|
|
|
|
|
|
|
|
|
|
|
| Dimension(mm) |
|
1.280×314×56 |
|
1.215×300×24 |
|
1.215×300×56 |
|
1.215×300×24 |
|
1.215×300×56 |
|
|
|
|
|
|
|
|
|
|
|
| Base |
|
Lighting apparatus all-in-one |
|
Lighting apparatus all-in-one |
|
Lighting apparatus all-in-one |
|
Lighting apparatus all-in-one |
|
Lighting apparatus all-in-one |
|
|
|
|
|
|
|
|
|
|
|
| Input Voltage(V) |
|
AC 220 |
|
AC 220 |
|
AC 220 |
|
AC 220 |
|
AC 220 |
|
|
|
|
|
|
|
|
|
|
|
| Power Factor |
|
more than 0.95 |
|
more than 0.95 |
|
more than 0.95 |
|
more than 0.95 |
|
more than 0.95 |
|
|
|
|
|
|
|
|
|
|
|
| Luminous Flux(lumen) |
|
4,365 |
|
5,150 |
|
4,800 |
|
6,4500 |
|
5,700 |
|
|
|
|
|
|
|
|
|
|
|
| Luminaire Efficiency(lm/W) |
|
87 |
|
99 |
|
93 |
|
107 |
|
95 |
|
|
|
|
|
|
|
|
|
|
|
| Color Temperature(K) |
|
5,700 |
|
5,700 |
|
5,700 |
|
5,700 |
|
5,700 |
|
|
|
|
|
|
|
|
|
|
|
| CRI(Ra) |
|
80 |
|
80 |
|
80 |
|
80 |
|
81 |
|
|
|
|
|
|
|
|
|
|
|
| Lifespan(H) |
|
50,000 |
|
50,000 |
|
50,000 |
|
50,000 |
|
50,000 |
|
|
|
|
|
|
|
|
|
|
|
| Beam Angle(˚) |
|
120 |
|
100 |
|
120 |
|
100 |
|
120 |
|
|
|
|
|
|
|
|
|
|
|
| Weight(g) |
|
5,600 |
|
3,700 |
|
3,900 |
|
3,700 |
|
3,900 |
|
|
|
|
|
|
|
|
|
|
|
| Lighting pattern |
|
Diffused Lighting |
|
Arch |
|
Diffused Lighting |
|
Arch |
|
Diffused Lighting |
|
| *Specification could be changed without notice. |
| Model |
|
HR030BA |
|
HR030BB |
| Power Consumption(W) |
|
30W |
|
30W |
|
|
|
|
|
| Dimension(mm) |
|
604×300×24 |
|
604×300×56 |
|
|
|
|
|
| Base |
|
Lighting apparatus all-in-one |
|
Lighting apparatus all-in-one |
|
|
|
|
|
| Input Voltage(V) |
|
AC 220 |
|
AC 220 |
|
|
|
|
|
| Power Factor |
|
more than 0.9 |
|
more than 0.9 |
|
|
|
|
|
| Luminous Flux(lumen) |
|
3,150 |
|
3,000 |
|
|
|
|
|
| Luminaire Efficiency(lm/W) |
|
105 |
|
100 |
|
|
|
|
|
| Color Temperature(K) |
|
5,700 |
|
5,700 |
|
|
|
|
|
| CRI(Ra) |
|
80 |
|
80 |
|
|
|
|
|
| Lifespan(H) |
|
50,000 |
|
50,000 |
|
|
|
|
|
| Beam Angle(˚) |
|
100 |
|
120 |
|
|
|
|
|
| Weight(g) |
|
2,200 |
|
2,400 |
|
|
|
|
|
| Lighting pattern |
|
Arch |
|
Diffused Lighting |
|
| *Specification could be changed without notice. |
|
|
|
 |
|
 |
